CABLE LASHERS
DCD FALCON LASHER (SERIES 61800)
-
The Falcon Lasher is a completely redesigned lasher, incorporating design elements of our previous Eagle, Lineman and Model K lashers, as well as new design concepts that simplify the lasher to make it more robust and lower maintenance.
This new lasher will single or double lash without strand traction. It is also equipped with a clutch handle to allow easy mounting and passing the unit around a pole without cutting the lashing wire or removing it from the drive wheels.
-
MAX STRAND: 1/2"
MAX LASH: 3-1/2"
WIRE SIZE: dia. 0.038" to 0.061"
SPOOL SIZE: 1,200' per coil
DIMENSIONS: 20" L x 11" W x 10" H
WEIGHT: 21.3 lb
-
LIST PRICE - $6,195.00
Rental Rate:
WEEKLY - $350.00 weekly
4 WEEK - $1,100.00
-
DCD EAGLE LASHER (SERIES 61700)
-
The Eagle Lasher was designed and built to meet the requirements of the 21st century cable lashing jobs. Sized to install CATV or fiber optic cables, it's lightweight, durable and simple. Since its introduction four years ago, the design has proven itself on the strand, from the Arctic Circle to Asia Minor.
-
MAX STRAND: 3/8”
MAX LASH: 2-1/4"
WIRE SIZE: dia. 0.038" to 0.061"
SPOOL SIZE: 1,200' per coil
DIMENSIONS: 18" L x 18" W x 8" H
WEIGHT: 24.0 lb
-
LIST PRICE - $5,795.95
-
DCD LINEMAN LASHER (SERIES 61400)
-
The Lineman™ Lasher is the pull type cable lasher for tough jobs, especially in dusty, wet or icy conditions. Use it to lash single or multiple cables up to 3" outside diameter and for single and double overlashing.
-
MAX STRAND: 1/2”
MAX LASH: 3"
WIRE SIZE: dia. 0.038" to 0.061"
SPOOL SIZE: 1,200' per coil
DIMENSIONS: 19-1/2" L x 12" W x 12" H
WEIGHT: 38.0 lb
-
LIST PRICE: $7,175.00
-
GMP C2 LASHER
-
Our compact Model C2 Cable Lasher is perfect for lashing smaller diameter aerial cables to supporting strand with stainless steel lashing wire. The new design improvements make the C2 equally suited for new construction or overlashing up to its full 1 7/8 in. bundle capacity.
Lashes single or bundled cables up to 1 7/8 in. (46mm) onto strand sizes 1/4 in. to 3/8 in. (6-10mm) diameter
New style strand lock swings out of the way for unobstructed overlashing
Simple wire routing yields either “normal” or “loose” wire tension
Cable Lasher Parallel Pull P/N 70467
Cable Lasher Parallel Pull P/N 70467
Dual wire magazines for loading two coils of stainless steel lashing wire
Typical wire dimensions: 1200 ft. x .045 in. (365 m x 1.1mm) or 1600 ft. x .038 in. (487m x 1mm)
Lightweight and compact: Unloaded weight 35 lbs. (16kgs.); only 10 in. O.D. x 18.5 in. long (25 x 47cm). The C2’s tapered housing eases passage through treed areas
The C2 Cable Lasher is furnished with a 6 ft. (1.6m) bridle rope with snap hooks, an instruction manual and a rugged, lightweight storage chest
The C2 and every GMP lasher is fully serviceable to “good-as-new” specifications at our factory and at factory-trained service locations around the globe
Like all GMP lashers, the C2 is built to last for many years of service. Components are CNC machined from alloy steel, stainless, bronze and aluminum castings to exacting tolerances and treated to withstand corrosion. Gear drives and sealed bearings assure maximum durability with minimal maintenance.
-
Designed to lash or overlash cables or bundles up to
1-7/8 in. (48 mm) diameter
Range of strand sizes: 1/4 in. - 3/8 in. (6 mm - 10 mm)
Weight: 35 pounds (16 kgs)
Wire Coil Dimensions (typical):
5.38 in. x 1.81 in. (137 mm x 46 mm)
Standard Wire Sizes:
1200 ft (365 m) of .045 in. (1.1 mm) diameter
1600 ft (487 m) of .038 in. (1.0 mm) diameter
-
LIST PRICE - $6,990.00
Weekly Rate - $300.00
4 Week Rate - $1,150.00
-
GMP J2 LASHER
-
The Model J2 Cable Lasher is used to lash a single aerial cable or numerous cables to a supporting strand or to an existing lashed cable with stainless steel lashing wire.
Will lash any single or multiple aerial cables up to 3 in. (76mm) diameter across on any suspension strand from 1/4 in. (6mm) to 7/16 in. (11mm). A factory modification will allow the lasher to accommodate 1/2 in. (12.7mm) strand if necessary.
Consists of a rotating drum supported on a carriage that provides the mounting for a driving mechanism, cable lifters, cable and strand rollers
Each of two recessed magazines will hold a 1200 ft. coil of .045 in. (365m of 1.1mm wire) lashing wire (or 450 ft. of .065 in.). The Lashing Wire is fully recessed and covered by a gate.
Features a fast setup procedure, quick coil loading, and automatic drum lock for easy span transfers and smooth forward travel
Cable Lasher Parallel Pull Accessory P/N 70467
J2 Lashers make overlashing easy. Just push down on the strand roller knob, rotate it a quarter turn and you can lash additional cables together on previously lashed cable
Positive internal gear to gear mechanism has no chains or belts to stretch, slip or break
Constructed with heat-treated, plated steel, stainless steel, brass and aluminum components. Contains sealed and oiless bearings to minimize maintenance and assure durability.
Pre-drilled and tapped at the factory for mounting of the lasher guard or “halo”. For use when lashing in overgrown areas.
The J2 and every GMP lasher is fully serviceable to “good-as-new” specifications at our factory and at factory-trained service locations around the globe.
The lasher is furnished with a rugged lightweight storage chest with corrosion resistant hardware, recessed latches and a moisture-proof, tongue-in-groove design for maximum protection when not in use
Supplied with a 6 ft. bridle rope assembly and snap hooks, and an information and operation manual
-
Designed to lash or overlash cables or bundles up to
3 in. (76 mm) diameter
Range of strand sizes: 1/4 in. - 7/16 in. (6 mm - 11 mm)
Weight: 46 pounds (21 kgs)
Wire Coil Dimensions (typical):
5.38 in. x 1.81 in. (137 mm x 46 mm)
Standard Wire Sizes:
1200 ft (365 m) of .045 in. (1.1 mm) diameter
1600 ft (487 m) of .038 in. (1.0 mm) diameter
-
LIST PRICE - $8,190.00
RENTAL RATE:
WEEKLY: $350.00
4 WEEK - $1,250.00
-
GMP APOLLO LASHER
-
The latest word in aerial cable lashing. Perfect for all telcom cable construction, including Coaxial and FTTx cable. With its light weight and parallel-pull capability, you’ll string cable quickly and easily, over all outside plant cable routes.
From the company that pioneered the modern automatic lasher with Western Electric back in the 1940’s…. comes Apollo… a machine that’s lightweight, easy-to-handle and simple to operate and maintain.
The newest addition to GMP’s line of proven lashers, Apollo has all of the versatility and performance features you need to easily handle today’s broadband lashing applications, solving all of the problems associated with pulling parallel to the strand and through densely crowded cable routes.
GMP engineers designed Apollo using computer-aided design and finite element analysis to achieve its high degree of durability without any excess weight. Then, we employed the very latest in high-speed CNC machining to make every part fit and perform exactly as designed. Like all our lashers, Apollo is built to last. After all, this is not just any spinner, it’s a GMP lasher.
-
Lashes any telcom cable/innerduct combination up to 4 in. (10cm) diameter
Parallel-pull capability overcomes all terrain obstacles
Interference-free over-lashing with no modifications
Positive slip-free gear drive (no belts) tested in excess of 1 million cycles
Lashes to strand sizes 1/4 in. to 3/8 in. (6 – 10 mm) diameter
Holds two coils of industry standard wire .045 in. x 1200 ft. (1.1mm x 365m) or .038 in. x 1600 ft. (1mm x 488m)
Provides adjustable tension of lashing wire, affording tight or loose lash
Wire tension constant regardless of amount on spool
No lasher backroll when pulling force removed
Front rollers guide cables through the machine
All smooth edges throughout provide 360° protection against cable damage
Ergonomic design makes it easy to handle
Manual clutch release allows speedy span transfers
The Apollo and every GMP lasher is fully serviceable to “good-as-new” specifications at our factory and at factory-trained service locations around the globe.
-
CALL FOR MORE INFO
-
GMP SUPER G LASHER
-
The newest and largest of the GMP Lashers, this unit is designed to lash a large single or a combination of aerial cables to a supporting strand. It can be used for new installs or with existing cables in place.
-
Lashes cable from about 2-1/2 to 5-1/4 in. outside diameter or multiple cables up to 5-3/4 in. combined outside diameter
Lashes on strand from 11/32 to 1/2 in. diameter with one or two spiral wrappings of .045, .061 or .065 in. diameter stainless steel wire
SuperG Large Capacity Cable Lasher
Nominal spacing between wraps is approximately 18-19 in. (46 to 48cm )
Parallel-pull capability overcomes most terrain obstacles
Wire tension constant regardless of amount on spool
Front rollers guide cables through the machine
All smooth edges throughout help protect against cable damage
Ergonomic design makes it easy to handle
Each lasher includes a 6 ft. bridle rope assembly with snap hooks, an information and operations manual and a heavy duty storage chest
Comes with 2 extra reels for easy loading in the field
-
CALL FOR INFO
-
FIBER BLOWERS
FREMCO MULTIFLOW RAPID FIBER BLOWER
-
Effective for both for single cable and relining
This machine is very flexible as it can both be configurated for single cable and for relining. It can blow many different combinations of ducts and microducts.
Tool free installation
The configuration and installation can be deployed without any usage of tools. This makes every fiber blowing job even more effective as the machine can quickly be adapted to blow different sizes of fiber/cable and ducts saving you a lot of time.
Cable blowing with either air or water
It is possible to install microducts and fiber optic cables using either air or water. With water assisted cable floating, you can achieve optimal results, especially when installing large cables or blowing long distances.
-
Fiber/Cable OD: 5.5-32 mm
Duct size OD: 10-63 mm
Preparation time: 8-10 min
Blowing distance: up to 16,404 feet
Floating distance (with water):up to 32,808 feet
-
LIST PRICE - $25,070.00
RENTAL RATE:
WEEKLY - $1,500.00
4 WEEK - $4,200.00
-
N/A
FREMCO MINIFLOW RAPID FIBER BLOWER
-
Fast cable blowing
The machine is capable of installing fiber cable at a speed up to 100 m/min. and up to a distance of 3.5 km making it a compact and efficient cable blowing machine.
Robust and compact
The machine is constructed in stainless steel and anodized aluminium, which makes it suited for use under rugged conditions at cable blowing locations.
Safe installation
The MiniFlow RAPID has a unique monitoring system, which continuously monitors the pushing force applied on the fiber cable. This makes it easy to stop the process before any damage happens to the cable.
-
Fiber/Cable OD: 3-12 mm
Duct size OD: 7-20 mm
Preparation time: 4 min
Blowing distance: up to 11,485 feet
-
LIST PRICE - $18,244.00
RENTAL RATE:
WEEKLY - $1,500.00
4 WEEK - $4,200.00
-
N/A
FREMCO DUCTROD RAPID W/ CONTROL VALVE
-
Built to push a duct rod into an underground duct. This hydraulic driven duct rodder is especially designed in close collaboration with Mills Limited to assist in rodding operations.
You have complete control of speed and pushing force. With DuctRod RAPID you can reach long distances up to 500 m. The DuctRod RAPID is equipped with an adjustable clamping unit securing the position in the manhole while preventing it from moving considerably.
-
Rod OD: 9-25 mm
Duct size OD: 10-40 mm
Preparation time: 2-4 min
Pushing Distance: up to 500 m
-
LIST PRICE: $12,000.00
-
N/A
PLUMETT MINIJET
-
Discover our multi-task cable and fiber blowing machine (optical fiber, coaxial or multipair).
For cables and fibers Ø 4 to 16 mm and ducts OD 7 to 42 mm.
The MiniJet™ jetting machine is designed for blowing or floating telecommunication cables and fibers (optical fiber, coaxial or multipair) or multiducts in preinstalled ducts.
This multipurpose jetting machine (4 in 1) is easy to use for the installation of cables, micro-cables or micro-ducts by air or water injection, and covers the most common cable diameters.
This MiniJet™ jetting machine high effectiveness significantly increases daily production. The belt drive system ensures excellent cable grip without damage and the clamping system absorbs cable diameter tolerances. In addition, its advanced design and construction improve installation performance. Its components are selected and manufactured to meet the highest requirements.
-
Standard version MiniJet™ with pneumatic drive
Type P02
Cable dia. [in] 0.16-0.63
Duct OD [in] 0.28-1.65
Drive unit Pneumatic
Max. air consumption of motor [ft3/min] 17.7 (at 58 psi)
Pushing force [lbf] 0-67
Max. speed [ft/min] 410
Max. air pressure [psi] 232
Max. water pressure [psi] 363
Dimension of apparatus l x w x h [in] 20.47 x 14.76 x 11.81
Dimension of apparatus with case l x w x h [in] 24.41 x 16.54 x 13.39
Dimension of tools and accessories case l x w x h [in] 24.41 x 16.54 x 12.20
Weight of machine [lbs] 44
Total shipping weight [lbs] 86
-
LIST PRICE - $32,107.00
RENTAL RATE:
WEEKLY - $1,500.00
4 WEEK - $4,200.00
-
N/A
PLUMETT SUPERJET
-
Discover our telecommunication cable and fiber blowing or floating machine (optical fiber, coaxial or multipair) or multiducts in preinstalled ducts.
For cables and fibers Ø 9 to 32 mm and for ducts OD 20 to 63 mm.
The SuperJet™ jetting machine is designed for blowing or floating telecommunication cables and fibers (optical fiber, coaxial or multipair) or multiducts in preinstalled ducts.
In addition to its ability to install a wide range of cables, this jetting machine is also well suited for laying multitubes. It is very easy to use and comes with a toolbox containing all the tools needed for maintenance and services. Its clamping system ensures good cable grip without damage while absorbing tolerances of the cable diameter.
it is equipped with a distance and speed counter for a better control of the installation.
-
Standard version SuperJet™ with hydraulic drive
Type H01
Cable dia. [in] 0.35-1.26
Duct OD [in] 0.79-2.48
Drive unit Hydraulic
Pushing force [lbf] 0-225
Max. speed [ft/min] 279
Hydraulic power pack, type of engine Honda Gasoline GX200
Hydraulic power pack, engine, max. power [kW] 4.3
Hydraulic power pack, engine, max. speed rpm [min-1] 3600
Max. air pressure [psi] 174
Max. water pressure [psi] 363
Dimension of apparatus l x w x h [in] 36.02 x 10.83 x 16.14
Dimension of apparatus with case l x w x h [in] 38.19 x 14.96 x 17.32
Dimension of tools and accessories case l x w x h [in] 23.62 x 15.75 x 9.84
Weight of machine [lbs] 82
Total shipping weight [lbs] 337
-
LIST PRICE - $36,600.00
RENTAL RATE:
WEEKLY - $1,600.00
4 WEEK - $4,500.00
-
N/A
PLUMETT ULTIMAZ E-25 JET
-
Discover our electric FTTx micro-cable blowing machine inside and outside buildings.
For FTTH micro-cables Ø 0.8 to 4.0 mm and micro-ducts OD 3 to 12.0 mm.
The UltimaZ™ E jetting machine is designed for pushing and blowing FTTx micro-cables in and out buildings or premises.
This small, very light, easy to transport, to prepare and to use jetting machine requires no tools and can be operated directly from its case.
Its speed, its automatic clamping setting and its predefined pushing force facilitate its operation and increase daily meter installation. The backlight display allows easy reading of the distance, speed and pushing force as well as the battery level.
This jetting device has a built-in electric motor, powered by a long life battery, which ensures a full day autonomy.
-
Standard version UltimaZ™
Type E25
Cable dia. [in] 0.031-0.157
Duct OD [in] 0.118-0.472
Drive unit Built-in electric motor
Pushing force [lbf] 1-5
Max. speed [ft/min] 656
Max. air pressure [psi] 232
Dimension of apparatus l x w x h [in] 10.04 x 3.15 x 7.68
Dimension of apparatus with case l x w x h [in] 19.69 x 16.54 x 9.06
Weight of machine [lbs] 9.5
Total shipping weight [lbs] 17.6
-
LIST PRICE - $9,500.00
RENTAL RATE:
WEEKLY - $800.00
4 WEEK - $2,200.00
-
N/A
PLUMETT OPTIJET
-
Discover our new intelligent telecommunication micro-cable and fiber units blowing machine (optical fiber, coaxial or multipair).
For micro-cables and fiber units Ø 1.5 to 8 mm and ducts OD 3 to 16 mm.
Our latest jetting machine, the OptiJet™, takes the next step in the innovations offered for blowing telecommunication micro-cables and fiber units (optical fiber, coaxial or multipair) into pre-installed micro-ducts.
An intelligent cable jetting machine by excellence, the OptiJet™ meets the most stringent protection requirements of the new generation of cables that incorporate ever more fibers in ever smaller diameters.
A true operator's assistant, the OptiJet™ is the only cable jetting machine on the market that automatically and quickly determines the maximum force supported by the cable, regardless of its diameter and construction. This unique feature, combined with a belt drive mode and a speed control mode, rather than motor torque, ensures optimal cable protection and the success of your installation.
The compact machine is easy to use thanks to an intuitive graphic interface, and its drive and clamping motors have a servo mode specifically developed for micro-cable installation. They are powered by long-life rechargeable batteries, which are sufficient for intensive use, day after day.
Another advantage is that the air from the compressor is only used for laying the cable which allows the use of smaller compressors, making the OptiJet™ an optimised solution, combining space and energy savings.
Finally, the OptiJet™ Reporting gives you unique access to a connected world of digital services available on an IoT platform. Not only does the OptiJet™ generate a detailed report, exportable directly, via its rugged tablet, by Wi-Fi or Bluetooth, but all cable laying and machine data are available in real time and simultaneously wherever you are, in the field or in the office. A whole new and evolving range of digital services is made available and accessible directly on the OptiJet™.
The OptiJet™ is a true field cable jetting machine and a worthy successor to the Microjet™. Its superior design and manufacturing, increase the performance and reliability of cable installation. Its components are selected and tested to meet the highest requirements and allow you to benefit from the latest technology and know-how of Plumettaz, the world's leading manufacturer of cable laying equipment.
The OptiJet™ is available in 2 versions, the OptiJet™ and the OptiJet™ Reporting. Each bringing an innovative answer to the world of cable laying installation.
-
Standard version OptiJet™
Type Reporting
Cable dia. [in] 0.059-0.315
Duct OD [in] 0.118-0.63
Drive unit Built-in electric motor (4 batteries included)
Pushing force [lbf] 2-34
Max. speed [ft/min] 328
Max. air pressure [psi] 232
Dimension of apparatus l x w x h [in] 12.20 x 15.16 x 15.55
Dimension of apparatus with case l x w x h [in] 24.41 x 16.54 x 16.14
Dimension of tools and accessories case l x w x h [in] 24.41 x 16.54 x 16.14
Weight of machine [lbs] 42
Total shipping weight [lbs] 99
-
CALL FOR MOR INFO
-
N/A
FIBER PULLERS
CONDUX FIBER PULLER
-
Condux Fiber Optic Cable Pullers consist of a hydraulic motor, variable speed foot control, manual flow control valve for adjusting maximum speed and a manually adjustable pressure relief valve for adjusting the ultimate pull tension.
Package includes: Pulling motor, Foot Control and Hoses. Remote mounting stand or a base mount, capstan and hydraulic power pack
-
CLICK HERE
-
LIST PRICE - $24,900.00
Rental Rate:
WEEKLY - $1,200.00
4 WEEK -$3,300.00
-
CONDUX CORNER CABLE GUIDE
-
Help protect your fiber when pulling into handholes or manholes with the corner cable guide.
-
5,000 lbs. (22,240 N) cable tension load capacity
-
LIST PRICE - $2,700.00
RENTAL RATE:
WEEKLY - $180.00
4 WEEK - $650.00
-
N/A
GMP SIDEWINDER FIBER OPTIC PULLER (TRAILER)
-
The GMP SideWinder Trailer-Mounted Fiber Optic Puller SideWinder Fiber Optic Pullerhas been designed to exceed the requirements of installing underground telecommunication cables, employing a 32 in. diameter single capstan to provide a controlled force to the pulling rope or tape.
-
Max. Pulling Capacity: 1100 lbs (500kg)
Max. Rope Speed: 200 ft/min (60m/min)
Capstan Diameter: 32 in. (813mm)
Dimensions:
Length: 123 in.(3124mm)
Overall Width: 69 in. (1753mm)
Height: 57 in.(1450mm)
Weight: 1400 lbs.(635kg)
Track: 60 in.(1676mm)
Tire Size: F78-14 205/75D14
Hitch Coupling: Lunette Ring (Pintle Eye) (P/N 32672) (See optional configuration below)
Lighting Adapter: 7-Pole RV Blade Type (P/N 29399) Supplied as standard (See optional configurations below)
Power Supply: Honda GX390 13 HP, Recoil Start, Overhead Valve, Cast Iron Cylinder Sleeve, 1.5 Gallon tank
Load indication: Calibrated gauge bezel
Main Drive: Fixed displacement tandem pumps to fixed displacement high torque motors.
Gear Box: In-line planetary gearbox (capstan drive)
-
LIST PRICE: $44,000.00
RENTAL RATE
WEEKLY - $1,300.00
4 WEEKS - $3,800.00
-
GMP ECAPSTAN FIBER PULLER
-
The GMP battery powered fiber optic cable puller is designed for the underground placement of fiber optic cable. It uses a rechargeable lithium Iron Phosphate Battery with an adjustable limit to the pulling tension of the capstan. The GMP fiber optic cable puller comes complete with an electric motor, battery, controller and a hand held trigger remoter control. Also the choice of a 32 or 42 in capstan. Chose either a vehicle receiver mount with support jack for mounting to a 2" square trailer hitch or the ground stand for remote deployment.
QUIET operation improves jobsite communication and safety 15,000 ft of cable pulling on a single battery charge*
NO engine, NO emissions
Adjustable pulling force and speed
Electronically controlled pulling setpoints from 0-800+ lbs
1 Man Operation
Data recording of pull force during operation
Hitch mount or ground stand capable
Uses capstans from 25" up to 42”
Quick push button operation to set capstan diameter, max pulling force, and pulling speed
Winch mode pull force override if pull force setpoint cannot complete pull
Battery life well over 2000 full charging cycles
Uses safe LiFePO4 technology
-
Motor Assembly P/N 71490 with 48Vdc 40 Ah Battery pack, charger, controller, and hand-held trigger remote. (Required)
Choose one size capstan:
Capstan size ( 32” or 42”) 32" Capstan P/N 36207 42" Capstan P/N 71491 and one type of stand Hitch Mount Stand Kit P/N 71499 Ground Stand Kit P/N 71498
-
RENTAL RATE
WEEKLY - $1,000.00
4 WEEKS - $2,800.00
-
COMING SOON
CONDUX 8.0” CABLE FEEDING SHEAVE
-
Plugs into conduit in manhole wall, guiding cable safely into the conduit regardless of the pulling angle
-
Part: 08617480
Size: 8 in (203 mm)
Slot Width : 6.00 in (152 mm)
Length: 14 in (356 mm)
Tube Width: 7.18 in (182 mm)
Tube Width: 7.94 in (202 mm)
 Capacity: 6,500 in (28,912 mm)
-
LIST PRICE - $1,504.00
RENTAL RATE:
WEEKLY - $80.00
4 WEEK - $240.00
-
MICRO TRENCHING EQUIPMENT
STV-300 GROUT MACHINE
-
Creates trenches wide and deep that are ideal for power and fiber optic installation, allowing you to save time and money by installing cable with minimal disruption to the surrounding.
Contact ABS Rents today to help you find the right Micro Trenching Attachment!
-
Trencher depth:
Trench width:
Height:
Length:
Width:
Attachment mass, no blade:
Blade diameter:
Blade speed:
Saw motor displacement:
-
LIST PRICE - Call For Pricing
-
COMING SOON
Ditch Witch RT80 Ride-On Tractor With MT16 Attachment
-
SUPERIOR AXLE CAPACITY
Featuring a best-in-class static-load rating of 35,407 lbs,
the RT80 is a workhorse for every job.
POWERFUL PLOWING
When equipped with a plow, the machine has a best-in-class
35,215 lbs of breakout force for greater power on plowing
applications.
EASIER MANEUVERABILITY
Equipped with a push-button and active management system
that returns the rear axle to center, the RT80 helps you
maneuver without constant steering adjustments.
SPEED CONTROL
A three-speed, shift-on-the-fly ground drive system allows
operators the ability to select the correct range, without
stopping work, to maximize performance.
ADVANCED CRUISE CONTROL
The RT80 uses a cruise-control system to sense engine load
and adjust speed to changing soil conditions, giving you better
traction in rough terrain and weather.
MODULAR DESIGN
With the simplest modular track-frame design in the industry,
you can quickly interchange tracks and tires for added
versatility and utilization.
-
-
Call For Reservation! (303) 990-3159
-
FULL SKID STEER MICRO TRENCHING ATTACHMENT
-
Side shift for the chute, allows faster, easier operation and alignment to the trench.
Chevron design gate allows for more precise flow control.
Tub is twice as thick as other solutions on the market.
Does not have rubber scrapers that can cause accelerated wear of the tub.
The hydraulic motor powering the mixer is outside the tub (chain drive).
The mixer motor is not exposed to the grout. No blown seals, bearings or motors.
Auto pilot speed control.
Super tight turn radius.
Faster overall speed than others.
Open design allowing very quick access to all parts and hoses.
Fuel gauge has a protective cover preventing grout from ruining it.
Of course the seat and steering wheel.
Operators can master the operation instantly, intuitively.
-
Overall Length 82.8 in 2.1 m
Wheelbase 44.6 in 1.13 m
Height 57.2 in 1.36 m
Ground clearance 5.375 in 137 mm
Overall Width 51.6 in 1.11 m
Mass 1900 lb 727 kg
-
LIST PRICE - $35,000
RENTAL RATE:
WEEKLY - $1,500
4 WEEK - $4,200
-
MICRO TRENCHING BLADES
-
Faster cutting longer lasting cleaner cutting, half the cost of factory blades,
and re-buildable with over a dozen options to choose from!
-
MAX STRAND: 1/2”
MAX LASH: 3"
WIRE SIZE: dia. 0.038" to 0.061"
SPOOL SIZE: 1,200' per coil
DIMENSIONS: 19-1/2" L x 12" W x 12" H
WEIGHT: 38.0 lb
-
CLICK HERE FOR MORE INFO
-
FIBER OPTIC SPLICING EQUIPMENT
KOMSHINE QX55 FIBER MASTER OTDR
-
● High precision 6 motor backbone fusion splicer for FTTx project
● Core alignment, which can clearly display the fiber core (at present, only Fujikura, Sumitomo and Komshine FX39 can meet the requirements in the market)
● High-capacity battery is 7800mAh, which can be used for about 400 cycles splicing and heating when fully charged.
● FX39 can use for outdoor construion for 288 & 128 core backbone cable
● FX39 appearance design closely follows the international counterparts
● FX39 carrying case designed with workbench, which can be loaded with more necessary construction tools (power meter,VFL, pliers, etc.)
● Other unique designs include machine can store 10000 sets of splicing results and 2000 sets of images/average splice loss is low than 0.01dB/real-time discharge correction, stable splicing accuracy/ Equip USB interface, convenient for data download and sw update.
-
6S fast splicing; 16S rapid heating / 4.3 inch LCD color display / 5000 times electrode service life / 7800mAh battery, 400 cycles of splicing and heating / Store 10000 sets of splicing results and 2000 sets of images.
-
LIST PRICE - $1,190
-
COMING SOON
KOMSHINE FX39 FUSION OPTICAL SPLICING KIT W/ FC-30 FIBER CLEAVER
-
Long-haul network testing
Access network testing
Live testing available
FTTx/PON testing through splitters
Compact, rugged, light weight 0.7kg
All new UI design with innovation
32dB Dynamic range
1m Event dead zone
Bult-in OPM、SLS、VFL、RJ45、FIP modules
Link Map & Pass/Fail judgment functions
Dual wavelengths testing
-
COMING SOON
-
LIST PRICE - $990.00
-
OTHER EQUIPMENT
DITCH WITCH RT115
-
Powered by a 121-hp (90-kW) turbocharged Tier 4 Deutz® engine and featuring a massive undercarriage and Quad Track System, the RT115 Quad is the ultimate trenching and plowing machine.
-
-
LIST PRICE - $189,000.00
Rental Rate:
WEEKLY - $4,300.00
4 WEEK - $12,900.00
-
MINI X BREAKER ATTACHMENT
-
N/A
-
N/A
-
LIST PRICE - $10,000
RENTAL RATE:
WEEKLY - $590.00
4 WEEK - $1,900.00
-
N/A
TEST SLUG
-
These Test Slugs are simple aluminum mandrels designed to be pulled through the duct to test for out of roundness. The slug diameters will fill approximately 70% of Schedule 40 ducting and 80% of Schedule 80 ducting. The ends are rounded for convenient pulling in either direction
-
N/A
-
LIST PRICE:
Test Slug - Aluminum for 1-1/2" Dia. Sched.40 Duct - $95.79
Test Slug - Aluminum for 2" Dia. Sched.40 Duct - $103.65
-
N/A
INNERDUCT SEAL KIT
-
DCD offers two types of seals. The Innerduct Seal is a screw-in type that requires one product for each duct size. The second type is a Universal Seal which is a tapered product suitable for all duct sizes from 1” to 2”. This is for use on short distance blowing where simply holding the seal against the end of the duct will do the job and save time. The Kit comprises all four Innerduct Seals plus the Universal Seal. A Control Valve and Rope Guides are also included.
-
N/A
-
LIST PRICE -
Universal Seal Kit with Control Valve: $1,137.45
-
N/A
CONTROL VALVE
-
The Control Valve is an integral part of the DCD blowing system. A ball valve allows control of air flow and quick disconnect fittings are attached at both ends. Three Rope Guides are included with each Control Valve purchased.
-
-
LIST PRICE - $159.91
-
INNERDUCT UNIVERSAL SEAL
-
The Innerduct Seal is a universal seal which is a tapered product suitable for all duct sizes from 1” to 2”. This is for use on short distance blowing where simply holding the seal against the end of the duct will do the job and save time.
-
1” - 2”
1.5 LB
-
LIST PRICE: $132.00
-
RUF ROD DELUXE W/ ACCESSORIES
-
The 7/16” Ruf Rod features our largest frame with a 40” diameter storage basket, which can hold up to 1500' of 7/16” fiberglass rod. The standard Ruf Rod includes a female rod end, a swivel rod end, and a pulling eye. The deluxe version includes accessories as listed below. All accessories that attach to the rod can be glued in the traditional manner or can be clamped with set screws. For extra security, they can be both glued and clamped.
-
7/16" X 1000 Ft.
WEIGHT: 144 LB
DIMENSIONS: 41-3/4” L 44-1/2 H 16-3/4 W
-
LIST PRICE - $2,934.47
-
N/A
TYPE 2 CLEVIS
-
The clevis by clevis style of swivel is the most common type and is the best for distributing side loads applied on the swivel due to its ability to pivot at either end. It does not allow the operator to push back without proper care and attention or the swivel may fold back on itself. Before rotation is recommenced, the line must be pulled straight or damage may occur to the swivel, as well as potential harm to nearby operators. DCD recommends that some type of restrictor be used to prevent the swivel from pivoting at the front or reamer end.
-
Dub-lite Swivel Swl 5,000 Lb 1-1/4" Dia. $254.19
Dub-lite Swivel Swl 8,500 Lb 2" Dia. $529.70
Dub-lite Swivel Swl 10,000 Lb 2-1/4" Dia. $620.53
Dub-lite Swivel Swl 15,000 Lb 2-1/2" Dia. $722.74
Dub-lite Swivel Swl 20,000 Lb 2-1/2" Dia. $795.73
-
Dub-lite Swivel Swl 5,000 Lb 1-1/4" Dia. $254.19
Dub-lite Swivel Swl 8,500 Lb 2" Dia. $529.70
Dub-lite Swivel Swl 10,000 Lb 2-1/4" Dia. $620.53
Dub-lite Swivel Swl 15,000 Lb 2-1/2" Dia. $722.74
Dub-lite Swivel Swl 20,000 Lb 2-1/2" Dia. $795.73
-
N/A
PLUMETT HYDRAULIC POWER PACK
-
Engine: Honda 8.0 / 9.0 HP air cooled @ 3,900 RPM
Hydraulic System: 6.0 gpm pump output with 11.5-gallon reservoir & extension hoses
-
Dimensions: 42” x 19” x 24”
Bare Weight: 261 lbs.
Shipping Weight: 310 lbs.
-
LIST PRICE - $4995.00
RENTAL RATE:
WEEKLY - $180
4 WEEK - $650
-
N/A
RALLY A FRAME
-
Reel stand
-
48 x 36 in
-
LIST PRICE - $1800.00
SALE ONLY
-
N/A
AIR HOSE
-
AIR HOSE FOR COMPRESSOR
-
50 FT
-
LIST PRICE - $180.00
RENTAL RATE:
WEEKLY - $40
4 WEEK - $120
-
N/A
BOBCAT MINI EXCAVATOR - E26
-
The Bobcat® E26 compact (mini) excavator features minimal tail swing to reduce the risk of damage to your machine and surrounding objects.
Easily maneuver established lawns, crowded jobsites and sensitive surfaces with the compact size and minimal ground disturbance.
Boost your working range with the standard long arm configuration.
-
Operating weight: 6489 lb
Bucket Digging Force: 5652 ibf
Max Reach at Ground Level: 192 in
Width: 61 in
Tail swing Type: Minimal
-
LIST PRICE - $28,500.00
RENTAL RATE:
WEEKLY - $900.00
4 WEEK - $3,000.00
-
CONDUX HYDRAULIC POWER PACK
-
This portable power source is matched perfectly to the requirements for the Condux Fiber Optic Cable Blower and Puller. Utilizing a small footprint, the 13hp Power Pack features a variable flow switch (from 5gpm to 8gpm) to ensure that every job can be covered with just one machine.
-
16 HP Power Pack
Hydraulic System: Open Center
Frame Type: Two Wheel Mobile Unit
-
LIST PRICE - $9000.00
RENTAL RATE:
WEEKLY - $180
4 WEEK - $650
-
N/A
FREMCO HYDRAULIC POWER PACK
-
Hydraulic driven fiber blowing machines are more effective and have a significantly lower total cost of ownership compared to an airdriven machine.
-
Hydralic oil tank capacity min. 5l/max. 7l
Working pressure nominal 100 bar (1450 psi)
Pressure relief valve set at 110 bar (1595 psi)
Guaranteed sound power level LWA 100 db
Oil temparature Max. 70° C (158°F)
Weight (w/o hydraulic oil) 54 kg (119 lbs)
Length 630 mm (25”)
Width 530 mm (21”)
Height 510 mm (20”)
-
LIST PRICE - $5450.00
RENTAL RATE:
WEEKLY - $180
4 WEEK - $650
-
N/A
